Rotating Beacon Fresnel 24VAC/DC YE
Article-Nr.
884.330.75
Type of fixing
Base mounting
Light colour
Yellow
More information
€483.19*
Prices excl. VAT plus shipping costs
Technical Data
Height
218.000000
Diameter
142.000000
Materials
PC; PC/ABS
Dome colour
Yellow
Housing colour
Black
Protection category
IP65
Connection
Screw terminals
cross-sectional area maximum
1,50mm² / 16AWG
Cable entry
Rubber pinch
Tension relief
Pull-out protection
Cable entry minimum
d = 5 mm
Type of fixing
Base mounting
Cable entry maximum
d = 7 mm
Working temperature minimum
-30°C
Product weight
672.000
Weight with packaging
761,00 g
Working temperature maximum
+50°C
Operating voltage
24V
Rated operational current
250.000000
Operating voltage type
AC/DC
Operating voltage frequency
50Hz
Operating voltage tolerance
+/- 10%
Rated operational voltage
24 VDC
Rated inrush current
2600 mA
Protection class
Protection class 2
Pollution degree
3
Overvoltage category
II
Light source
LED
Optical signal image
Revolving
Rotation speed (rpm)
60.000000
Service life optical
50,000 h minimum
Conforms with CE
Yes
Conforms with RoHS directive
Yes
WEEE
Yes
Conforms with ATEX-directive
No
Conforms with CCC
No
Conforms with CCC-Ex
No
Conforms with UL
No
Conforms with FCC
No
Conforms with ISED
No
EAC certificate available
Yes
Conforms with UKCA (Importer)
Yes
Conforms with AS-I
No
Conforms with RoHS CN
No
Conforms with CMIM
No
Conforms with DNV
No
Conforms with VdS
No
Conforms with TÜV
No
